OEM


OEM Camera Solutions

Raptor is working with many major OEMs and instrumentation companies across the world in surveillance, aerospace, scientific and industrial applications, who need custom designs to meet their exact imaging and detection requirements.

Camera options:
• With or without camera housing (Mechanical re-design to customer specification)
• Remote heads
• Electronic re-design to customer specifications
• Flexible voltage supply
• Increased resistance to shock, vibrations and temperature (according to the housing specification)

View OEM Camera Solutions

Space ready / modified COTS OEM Camera Solutions

Raptor offers a range of next generation digital camera cores, from UV to SWIR, perfoect for integration into LEO CubeSat payloads.

Raptor cameras are on LEO satellites revolving at an altitude between 160 to 2,000 kilometers flying at approximately 17,000 mph. Some of our cameras have been operational for over 18 months. We offer LEO camera solutions from UV (180nm) to SWIR (1700nm).  We offer flight-ready COTS options as well as custom OEM designs in platforms from 1U to 10U.

Options include:

  • MilSpec / industrial grade components inspected to IPC A610 Class 3 standards
  • All workmanship carried out to IPC-JSTD001GS standards
  • No C-Mount, M42
  • Board level, supplied with/without conformal coatings
  • Extended operational temperature -40°C to +75°C
  • Flexi-rigid electronics to fit specific EO systems
  • Customized mechanics
  • Digital video output eg HD-SDI, Samtec, custom
View Space ready / modified COTS OEM Camera Solutions

Hyperspectral Imaging OEM Solutions

With high measurement rates, exceptional spectral and spatial resolution, and a flexibly adjustable field of view, the HIS 320 enables real-time in-line monitoring – even on fast moving objects. It is the perfect system for OEMs, with easy integration into in-house software.

View Hyperspectral Imaging OEM Solutions

CMOS OEM Solutions

EMCCD

Raptor offers a range of next-generation digital CMOS mono cores, enabling ultimate sensitivity similar to II or EMCCD, for passive digital night vision and surveillance. These global shutter cameras are ultra-compact, rugged and low power making them ideal for a range of Electro-Optic systems.

  • Waveband range: 0.3μm – 1.1μm
  • Range of resolutions: SVGA and Full HD format
  • Range of pixel sizes: 4.5µm and 9µm
  • Range of interfaces including Camera Link, HD-SDI, etc.
  • Other custom options available including sensors, mechanics, electronics and optics

Minimum order quantities apply.

View CMOS OEM Solutions

Vis-SWIR InGaAs OEM solutions

Raptor is the market leader in high-end SWIR and Vis-SWIR cameras. We offer a range of OEM formats, including HD-SDI, perfect for EO integration where space is at a premium.

  • Range of resolutions: 320 x 256, 640 x 512, 1280 x 1024 pixels
  • Range of pixel pitches: 30μm, 15μm and 10μm
  • SWIR and Vis-SWIR options, with low noise options (18e- typical)
  • Cooling options including: TECless, Stabilized and Deep Cooled
  • Extended operational temperature from -40°C to +75°C
  • Firmware features including 3-point NUC, ALPD functionality, image flip, crosshair, edge and contrast enhancement
  • HD-SDI SMPTE-274M interface: Provides full HD resolution 1080p/30
View Vis-SWIR InGaAs OEM solutions

EMCCD OEM Solutions

Raptor has led the way in EMCCD cameras for both surveillance ruggedized board level cores through to high end deep-cooled scientific applications.

  • Waveband range: 0.3μm – 1.1μm
  • Range of resolutions 128 x 128, 768 x 576, 1024 x 1024 pixels
  • Range of pixel pitches: 26μm, 10μm and 8μm
  • Range of frame rates from 25Hz to 1kHz full resolution
  • Cooling options include deep cooled to -70°C
  • Firmware features include Binning and ROIs
View EMCCD OEM Solutions

Intensified CCD OEM Solutions

Raptor offers a range of Intensified CCD camera options that are 50% of the size and weight of our closest competitor.

  • Intensified CCD with a Gen II image intensifier
  • Waveband range: 0.2μm – 0.85μm
  • 1024 x 1024 resolution
  • 13µm pixel
  • Nanosecond gating
  • Custom interface

Minimum order quantities apply.

View Intensified CCD OEM Solutions

Spectroscopy CCD OEM Solutions

Raptor offers a range of CCD and EMCCD based cooled detectors to meet OEM requirements across a range of spectroscopy applications.

  • Waveband range: 0.2μm – 1.1μm
  • Range of resolutions and pixel sizes: 1024 x 256, 2048 x 512, 2048 x 264
  • FI/BI (DD) and OE options
  • TE cooling to -40°C and to -70°C
  • Choice of interfaces

Minimum order quantities apply.

View Spectroscopy CCD OEM Solutions

Imaging CCD OEM Solutions

Raptor offers a range of high-performance CCD cameras in varying formats. . These global shutter cameras are ultra-compact, rugged and low power making them ideal for a range of Electro-Optic systems.

  • Waveband range: 0.3μm – 1.1μm
    Range of resolutions and pixel sizes
    FI/BI (DD) and OE options
    TE cooling options to -40°C and -70°C
    Range of interfaces including Camera Link, USB, GigE and custom interfaces.
    Other custom options available including sensors, shutters, mechanics, electronics and optics

Minimum order quantities apply.

View Imaging CCD OEM Solutions
