Owl 320 HS

High Speed, Digital SWIR Camera


The Owl 320 HS offers the fastest frame rates available in the Owl camera line-up (up to 349Hz in full frame resolution), perfect for high speed VIS-SWIR applications (0.6µm – 1.7µm). With Region of Interest (ROI) control, faster frame rates in the kHz region are achievable by setting smaller ROIs.

Featuring a State of the Art high sensitivity InGaAs sensor, the camera offers a full-frame pixel resolution of 320 x 256, with a pixel pitch of 30µm x 30µm.

Key Features and Benefits
High-Speed SWIR Technology

  • SWIR technology | Enables high-speed imaging from 0.6µm to 1.7µm
  • Easy control of camera parameters | Control of Exposure, Frame rate, Gain, Temperature, trigger, etc
  • Ultra compact, Low power (< 5W) | Ideal for hand-held, mobile or airborne systems
  • Rugged, No fan | Enables integration into UAV, handheld or Electro-Optic systems

Scientific

  • Astronomy
  • Beam Profiling
  • Hyperspectral Imaging
  • Semiconductor Inspection
  • Solar Cell Inspection
  • Thermography
  • OWL 320 SWIR camera coupled to a rugged SWIR 14mm
